HOW TO USE THE COMMAND HUB

The i-Series Command Hub provides comprehensive dehumidifier controls and detailed real-time data about the drying environment as well as job hours, self-diagnosis messages, maintenance reminders and operating status.

To take advantage of the Command Hub's remote monitoring and operation via Bluetooth and WiFi, visit the Dri-Eaz Command Center Pro page: LegendBrands.com/resources/command-center

Home Screen Views

Unit OFF

Unit must be plugged in.

Top display bar:

Job hours and status indicators

Bottom menu bar:

Press ch_menu MENU to access settings and configuration controls

Press CH_Purge PURGE to pump out condensate tank

Press CH_Power ON/OFF to turn unit on.

Home Screen



Unit ON - Drying Mode

Press ON/OFF key to switch unit on.

Top display bar:

Job hours and status indicators

Information display:

Inlet (ambient) and outlet temperature and relative humidity (RH%), plus Grains Per Pound (GPP) and GPP change

Bottom menu bar:

Press ch_menu MENU to access settings and configuration controls

Press CH_Purge PURGE to pump out condensate tank

Press CH_Power ON/OFF to turn unit off.

Home Screen -- Running-1



Unit ON - Humidity Control Mode

Press ON/OFF key to switch unit on.

Press CH_menu MENU to access settings and configuration controls

Press AdjustRH ADJUST RH.

Press Humidistat-on-off to turn Humidistat on.

Press up/down arrows to set target RH% between 10% and 50% relative humidity. The default humidistat setting is 35% RH.

Press SET when done.

To view chart tracking temperature and humidity, press CHART.

Press CH_Purge PURGE to pump out condensate tank

Press CH_Power ON/OFF to turn unit off.

Humidistat screen
